Bussmann

NON-2-1/2 General Purpose Fast Acting Non-Current Limiting One-Time Fuse, 2.5 A, 250 V AC/125 V DC, 50 kA Interrupt, Class: H, Cylindrical Body

MFR:
Eaton
MFR #:
NON-2-1/2
UPC:
051712300186
Item #:
107644

Availability

Location Available Qty
Available Available to Order
$25.04 each

Bussmann One-Time Fuse, General Purpose Fast Acting Non-Current Limiting, Series: NON, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 2.5 A, 250 V AC/125 V DC, 50 kA Interrupt, Class: H, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Single Element, Melamine, 0.56 in Dia x 2 in L Body Size

Manuals and Documentation

Features

  • Protect lighting, heating and other circuits not subject to temporary surges and where available short circuit currents are relatively low
  • Noon one time fuses do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
  • Use Bussmann advanced protection Fusetron™ FRN-R or ultimate protection Low-Peak™ LPN-RK dual element, time delay fuses
  • For general purpose circuits, size at amp rating of circuit
  • For motor circuits, size at 300% to 400% according to the NEC motor ampacity tables 430.247 to 430.250 per 430.6(A)(1)
Manufacturer Part Number NON-2-1/2
Brand Bussmann
Manufacturer Eaton
UPC 051712300186
EAN 5027590408233
Country Of Origin MX
Amperage Rating 2.5 A
Material Melamine
Mounting Type Holder
Series NON
Type General Purpose Fast Acting Non-Current Limiting
Voltage Rating 250 V AC/125 V DC
Alternative Part Number 7611341
Manufacturer Item Status Active
Country USA
Standards Approvals CE Marked
Application For light duty circuit locations, safety and security systems
Body Size 0.56 in Dia x 2 in L
Body Type Cylindrical
Class H
Element Single
Indicating Non Indicating Non-Indicating
Interrupt Rating 50 kA
Rejection Non Rejection Non-Rejection
Terminal Type Ferrule
