33683 Under Voltage Trip, 380/480 V AC/DC, 50/60 Hz, 4.5/200 VA Power Rating
- MFR:
- Schneider Electric
- MFR #:
- 33683
- Item #:
- 1017485
33683 Under Voltage Trip, 380/480 V AC/DC, 50/60 Hz, 4.5/200 VA Power Rating
- MFR #:
- 33683
- Item #:
- 1017485
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$95.00
each
This time delay unit is an auxiliary that can be combined with an undervoltage release (MN). It must be associated with a 380-480 VAC MN undervoltage release. It eliminates the risk of nuisance tripping due to transient voltage dips lasting from 200ms to 3s. Its power supply is 380-480VDC or 380-480VAC 50/60Hz. This time delay unit has 4 adjustable steps (0.5s - 1s - 1.5s - 3s). It is an external accessory and can be mounted in the switchboard.
Manuals and Documentation
| Catalog Number | 33683 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Application | Control |
| Mounting | External Mounting |
| Response Time | 0.5 s;1 s;1.5 s;3 s |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=841424&lang=en-us |
| GTIN | 03303430336839 |
| Item Type | Time delay relay |
