9007MS01G0100 Miniature Potted Limit Switch, 240 VAC/28 VDC, 10 A, 1CO 1 Form C SPDT Contact, 1 Poles
- MFR:
- Schneider Electric
- MFR #:
- 9007MS01G0100
- UPC:
- 785901711629
- Item #:
- 1017153
Discontinued
9007MS01G0100 Miniature Potted Limit Switch, 240 VAC/28 VDC, 10 A, 1CO 1 Form C SPDT Contact, 1 Poles
- MFR #:
- 9007MS01G0100
- UPC:
- 785901711629
- Item #:
- 1017153
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
LIMIT SWITCH 240VAC 10AMP MS +OPTIONS
Manuals and Documentation
| Catalog Number | 9007MS01G0100 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | ON END,SNAP ACTION,VERTICAL APPROACH, 1 DIRECTION |
| Actuator | SPRING RETURN PLUNGER STAINLESS STEEL - |
| Amperage Rating | 10 |
| Application | 9007MS/ML,MINIATURE POTTED,PLUNGER HEAD |
| Connection | PRE-WIRED CABLE BOTTOM |
| Contact Configuration | NC-NO |
| Enclosure | NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250 |
| Mounting | By The Body |
| Operating Cycles | 100000 CYCLES |
| Special Features | FIXED,METAL |
| Standard | 10 GN 75-1200 HZ)IEC 60068-2-6,35 GN 9 MS IEC 60068-2-27,E78403-LR 25490 CLASS 32 11 03,IP67 IEC 60529,UL-CE-CSA |
| UPC | 785901711629 |
| GTIN | 00785901711629 |
| Item Type | LIMIT SWITCH,PLUNGER HEAD |
| Size | 0.62 IN,1.56 IN,1.75-1.75 IN |
| Operating Temperature | -40-220 A Degrees F |
| Voltage Rating | 100 MA 125 V AC-30 MA 28 V DC |
